Technical Data

Green Products

Data Sheet N1552, Rev. -

• Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113

(86) 25-87123907

•

• FAX (86) 25-87123900 • World Wide Web Site - http://www.sangdest.com.cn • E-Mail Address - sales@ sangdest.com.cn •

MBR540S

Marking Diagram:

Where XXXXX is YYWWL

= Forward Current (5A)

= Reverse Voltage (40V)

= Device Type

= Year

= Week

= Lot Number

Cautions：Molding resin

Epoxy resin UL:94V-0

Ordering Information:

Device

Package

Shipping

MBR540S

TO-277B(Pb-Free)

5000pcs/ reel

For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging

Specification.

Maximum Ratings:

Characteristics

Symbol

Condition

Max.

Units

Peak Inverse Voltage

VRWM

Average Forward Current

IF(AV)

50% duty cycle @TC =80°C,

rectangular wave form

Peak One Cycle Non-

Repetitive Surge Current

IFSM

8.3 ms, half Sine pulse

150
