MBR540S

MBR540S SCHOTTKY RECTIFIER

Applications:

•

Switching power supply

•

Converters

•

Free-Wheeling diodes

•

Reverse battery protection

•

Center tap configuration

Features:

•

Designed as Bypass Diodes for Solar Panels

for High Thermal Reliability

•

High Forward Surge Capability

•

Ultra Low Forward Voltage Drop

•

Excellent High Temperature Stability

•

This is a Pb − Free Device

•

All SMC parts are traceable to the wafer lot

•

Additional testing can be offered upon request

Mechanical Dimensions: In mm

TO-277B(JK)
