background image
SANGDEST
MICROELECTRONICS
Technical Data
Green Products
Data Sheet N1552, Rev. -
• Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
(86) 25-87123907
•
• FAX (86) 25-87123900 • World Wide Web Site - http://www.sangdest.com.cn • E-Mail Address - sales@ sangdest.com.cn •
MBR540S
Electrical Characteristics:
Characteristics
Symbol
Condition
Max.
Units
Forward Voltage Drop
VF1
@ 5A, Pulse, TJ = 25 °C
0.52
V
VF2
@ 5A, Pulse, TJ = 125 °C
0.45
V
Reverse Current
IR1
@VR = rated VR
TJ = 25 °C
1
mA
IR2
@VR = rated VR
TJ = 125°C
100
mA
* Pulse Width < 300µs, Duty Cycle <2%
Thermal-Mechanical Specifications:
Characteristics
Symbol
Condition
Specification
Units
Junction Temperature
TJ
-
-55 to +125
°C
Storage Temperature
Tstg
-
-55 to +125
°C
Maximum Thermal
Resistance Junction to
Ambient
RθJA
DC operation
60
°C/W
Maximum Thermal
Resistance Junction to Lead
RθJL
DC operation
3
°C/W
Approximate Weight
wt
-
0.08
g
Case Style
TO-277B
