SL28610

........................ DOC #: SP-AP-0078 (Rev. 1.0) Page 7 of 23

Byte 6: Control Register 6

Bit

@Pup

Name

Description

7

HW

PLL2 N DIV 8

This is a read only register of the multiplier used for PLL2 M and N Dividers

HW= Read Only

6

HW

PLL2 N DIV 9

5

HW

PLL2 M DIV 5

4

HW

PLL2 M DIV 4

3

HW

PLL2 M DIV 3

2

HW

PLL2 M DIV 2

1

HW

PLL2 M DIV 1

0

HW

PLL2 M DIV 0

Byte 7: Control Register 7

Bit

@Pup

Name

Description

7

HW

PLL2 N DIV 7

This is a read only register of the multiplier used for PLL2 N Divider

HW= Read Only

6

HW

PLL2 N DIV 6

5

HW

PLL2 N DIV 5

4

HW

PLL2 N DIV 4

3

HW

PLL2 N DIV 3

2

HW

PLL2 N DIV 2

1

HW

PLL2 N DIV 1

0

HW

PLL2 N DIV 0

Byte 8: Control Register 8

Bit

@Pup

Name

Description

7

HW

PLL3 M DIV 7

This is a read only register of the multiplier used for PLL3 M Divider

HW= Read Only

6

HW

PLL3 M DIV 6

5

HW

PLL3 M DIV 5

4

HW

PLL3 M DIV 4

3

HW

PLL3 M DIV 3

2

HW

PLL3 M DIV 2

1

HW

PLL3 M DIV 1

0

HW

PLL3 M DIV 0

Byte 9: Control Register 9

Bit

@Pup

Name

Description

7

HW

PLL3 N DIV 7

This is a read only register of the multiplier used for PLL3 N Divider

HW= Read Only

6

HW

PLL3 N DIV 6

5

HW

PLL3 N DIV 5

4

HW

PLL3 N DIV 4

3

HW

PLL3 N DIV 3

2

HW

PLL3 N DIV 2

1

HW

PLL3 N DIV 1

0

HW

PLL3 N DIV 0
