Data Sheet

ADP3330

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

Input Supply Voltage

−0.3 V to +16 V

Shutdown Input Voltage

−0.3 V to +16 V

Power Dissipation

Internally limited

Operating Ambient Temperature Range

−40°C to +85°C

Operating Junction Temperature Range

−40°C to +125°C

θJA (4-Layer Board)

165°C/W

θJA (2-Layer Board)

190°C/W

Storage Temperature Range

−65°C to +150°C

Lead Temperature (not a range)

(Soldering 10 seconds)

300°C

Vapor Phase (60 seconds)

215°C

Infrared (15 seconds)

220°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

ESD CAUTION

Rev. C | Page 5 of 16
