3 / 52 page  Data Sheet ADRF6620 Rev. 0 | Page 3 of 52 SPECIFICATIONS VCCx = 5 V, TA = 25°C, unless otherwise noted. Table 1. Parameter Test Conditions/Comments Min Typ Max Unit LO INPUT Internal LO Frequency Range 350 2850 MHz External LO Frequency Range LO_DIV_A = 00 350 3200 MHz LO Input Level −6 0 +6 dBm LO Input Impedance 50 Ω RF INPUT Input Frequency 700 2700 MHz Input Return Loss 12 dB Input Impedance 50 Ω RF DIGITAL STEP ATTENUATOR Attenuation Range Step size = 1 dB 0 15 dB POWER SUPPLY 4.75 5.0 5.25 V Power Consumption LO output buffer disabled External LO + IF DGA enabled 1.3 W Internal LO + IF DGA enabled 1.7 W Only IF DGA enabled 0.6 W Power-Down Current 6 mA RF INPUT TO IF DGA OUTPUT SYSTEM SPECIFICATIONS VCCx = 5 V, TA = 25°C, high-side LO injection, fIF = 200 MHz, internal LO frequency, IF DGA output load = 150 Ω, and 2 V p-p differential output with third-order low-pass filter, unless otherwise noted. For mixer settings for maximum linearity, see Table 16. All losses from input and output traces and baluns are de-embedded from results Table 2. RF Switch + Balun + RF Attenuator + Mixer + IF DGA Parameter Test Conditions/Comments Min Typ Max Unit DYNAMIC PERFORMANCE AT fRF = 900 MHz fIF = 200 MHz Voltage Conversion Gain 12 dB Output P1dB 18 dBm Output IP3 1 V p-p each output tone, 1 MHz tone spacing 43 dBm Output IP2 1 V p-p each output tone, 1 MHz tone spacing 78 dBm Noise Figure Noise figure optimized 16 dB DYNAMIC PERFORMANCE AT fRF = 1900 MHz fIF = 200 MHz Voltage Conversion Gain 11 dB Output P1dB 18 dBm Output IP3 1 V p-p each output tone, 1 MHz tone spacing 45 dBm Output IP2 1 V p-p each output tone, 1 MHz tone spacing 75 dBm Noise Figure Noise figure optimized 18.5 dB DYNAMIC PERFORMANCE AT fRF = 2100 MHz fIF = 200 MHz dB Voltage Conversion Gain 10.5 dBm Output P1dB 18 dBm Output IP3 1 V p-p each output tone, 1 MHz tone spacing 45 dBm Output IP2 1 V p-p each output tone, 1 MHz tone spacing 66 dBm Noise Figure Noise figure optimized 19 dB DYNAMIC PERFORMANCE AT fRF = 2700 MHz fIF = 200 MHz Voltage Conversion Gain 9 dB Output P1dB 18 dBm Output IP3 1 V p-p each output tone, 1 MHz tone spacing 44 dBm Output IP2 1 V p-p each output tone, 1 MHz tone spacing 74 dBm Noise Figure Noise figure optimized 21 dB |
|
