Data Sheet

ADRF6620

Rev. 0 | Page 9 of 52

ABSOLUTE MAXIMUM RATINGS

Table 7.

Parameter

Rating

VCCx

−0.5 V to +5.5 V

RFSW0, RFSW1

−0.3 V to +3.6 V

RFIN0, RFIN1, RFIN2, RFIN3

20 dBm

LOIN−, LOIN+

16 dBm

REFIN

−0.3 V to +3.6 V

IFIN−, IFIN+

−1.2 V to +3.6 V

CS, SCLK, SDIO

−0.3 V to +3.6 V

VTUNE

−0.3 V to +3.6 V

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Maximum Junction Temperature

150°C

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

Table 8. Thermal Resistance

Package Type

θJC

Unit

48-Lead LFCSP

1.62

°C/W
