ADRF6620ACPZ-R7 Datasheet(PDF) 6 Page - Analog Devices |
|
|
|||||||||||||||||||||||||||||
ADRF6620ACPZ-R7 Datasheet(HTML) 6 Page - Analog Devices |
|
|
6 / 52 page  ADRF6620 Data Sheet Rev. 0 | Page 6 of 52 RF INPUT TO MIXER OUTPUT SPECIFICATIONS VCCx = 5 V, TA = 25°C, high-side LO injection, fIF = 200 MHz, external LO frequency, and RF attenuation = 0 dB, unless otherwise noted. Mixer settings configured for maximum linearity (see Table 16). All losses from input and output traces and baluns are de-embedded from results. Table 4. RF Switch + Balun + RF Attenuator + Mixer Parameter Test Conditions/Comments Min Typ Max Unit VOLTAGE GAIN Differential 255 Ω load −4 dB MIXER OUTPUT IMPEDANCE Differential (see Figure 87) 255 Ω DYNAMIC PERFORMANCE AT fRF= 900 MHz Voltage Conversion Gain −2 dB Input P1dB 17 dBm Input IP3 −5 dBm each input tone, 1 MHz tone spacing 40 dBm Input IP2 −5 dBm each input tone, 1 MHz tone spacing 65 dBm Noise Figure 15 dB LO to RF Leakage −70 dBm RF to LO Leakage −60 dBc LO to IF Leakage −32 dBm RF to IF Leakage With respect to 0 dBm RF input power −45 dBc Isolation1 Isolation between RFIN0 and RFIN3 −52 dBc DYNAMIC PERFORMANCE AT fRF =1900 MHz Voltage Conversion Gain −3 dB Input P1dB 17 dBm Input IP3 −5 dBm each input tone, 1 MHz tone spacing 40 dBm Input IP2 −5 dBm each input tone, 1 MHz tone spacing 62 dBm Noise Figure 17 dB LO to RF Leakage −60 dBm RF to LO Leakage −50 dBc LO to IF Leakage −35 dBm RF to IF Leakage With respect to 0 dBm RF input power −43 dBc Isolation1 Isolation between RFIN0 and RFIN3 −47 dBc DYNAMIC PERFORMANCE AT fRF = 2100 MHz Voltage Conversion Gain −3.5 dB Input P1dB 18 dBm Input IP3 −5 dBm each input tone, 1 MHz tone spacing 40 dBm Input IP2 −5 dBm each input tone, 1 MHz tone spacing 54.5 dBm Noise Figure 18 dB LO to RF Leakage −60 dBm RF to LO Leakage −40 dBc LO to IF Leakage −35 dBm RF to IF Leakage With respect to 0 dBm RF input power −40 dBc Isolation1 Isolation between RFIN0 and RFIN3 −45 dBc DYNAMIC PERFORMANCE AT fRF = 2700 MHz Voltage Conversion Gain −4.7 dB Input P1dB 19 dBm Input IP3 −5 dBm each input tone, 1 MHz tone spacing 40 dBm Input IP2 −5 dBm each input tone, 1 MHz tone spacing 56 dBm Noise Figure 21 dB LO to RF Leakage −60 dBm RF to LO Leakage −45 dBc LO to IF Leakage −40 dBm RF to IF Leakage With respect to 0 dBm RF input power −42 dBc Isolation1 Isolation between RFIN0 and RFIN3 −41 dBc 1 Isolation between RF inputs. An input signal was applied to RFIN0 while RFIN1 to RFIN3 were terminated with 50 Ω. The IF signal amplitude was measured at the mixer output. The internal switch was then configured for RFIN3, and the feedthrough was measured as a delta from the fundamental. |
|
